What is a serial port screen? Serial port screen composition and serial port screen solution part three

Serial screen hardware solution

Serial screen hardware solution:

Basic series serial port screen based on STM32 MCU+FPGA

IoT series serial screen based on ITE9854, ITE976 and ITE9866

(3) F series serial port screen based on ADSTAR

(4) Medical grade M series serial port screen based on Allwinner F1C100S

Serial screen system software: Based on different serial screen hardware, supporting system software is developed. The system software mainly consists of display driver module, project file analysis module, touch screen driver module, serial communication module, command analysis module, storage module, etc. Each module Work together to complete the decoding of "project files" and analyze and execute project configurations, pictures, videos, LUA scripts, etc.; the serial communication module internally implements various standard protocols such as Dacai configuration protocol, MODBUS protocol, and Mitsubishi FX2N protocol.

LCD Screen configuration software: VisualTFT is a configuration software developed based on MFC. It includes a complete serial screen development kit, supports project creation of all series models, and provides rich configuration controls, interface editing, variables, logic processing, MINIC scripts, and LUA. Engineering functions such as scripts, multi-language settings, and project configurations, various tools such as command assistants, icon generators, font generators, and audio converters, and a "virtual serial screen" that is innovative in the serial screen industry for direct simulation operation, providing Detailed help documentation, project DEMO, online documentation, etc.
